Description
-
Product Specifications:
-
Mobile Network Communications: Supports LTE Cat M1 (4G) with fallback to GSM/GPRS (2G), ensuring versatile and future-proof connectivity.
-
Operating Voltage: 6.0V to 50.0V DC, accommodating a wide range of vehicle power systems.
-
Antennas: Internal GNSS and GSM antennas; option for external GNSS antenna via SSMB connector.
-
SIM Card Format: Micro SIM (3FF), push-push style.
-
Accelerometer: Integrated 3-axis accelerometer for motion detection and driver behavior analysis.
-
Battery Capacity: Internal 510mAh lithium-polymer backup battery, providing approximately 9 hours of continuous operation or up to 20 days in low-power mode with daily updates.
-
Inputs/Outputs:
-
6 digital inputs.
-
5 digital outputs (60V, 0.5A maximum, MOSFET open drain).
-
1-Wire interface for driver identification or temperature sensing.
-
CANBus interface supporting FMS 2.0 and OBD2 protocols.
-
2 RS232 serial ports.
-
2 ADC inputs (0–5V and 0–15V).
-
-
Ingress Protection: IP67-rated, ensuring complete protection against dust and water immersion.
-
Dimensions: Compact design for easy installation.
-
-
Features:
-
Real-time Tracking: Provides accurate, real-time location updates for vehicles.
-
Geofencing: Allows setting up virtual boundaries with alerts when the vehicle crosses them.
-
Driver Identification: Supports iButton for driver ID applications, enhancing security and accountability.
-
CANBus Integration: Compatible with FMS and OBD2 protocols for vehicle diagnostics and monitoring.
-
Low Power Consumption: Operates efficiently with minimal power usage, featuring sleep modes to reduce battery drain when the vehicle is stationary.
-
Over-the-Air (OTA) Updates: Supports firmware updates remotely, ensuring the device remains up-to-date with the latest features and improvements.
-
Durable Design: Compact form factor with a robust, waterproof enclosure, suitable for various installation environments.
-
