| Module |
Name: Quectel BG95-M3 with Teltonika TM2500
|
| Technology |
LTE CAT M1/NB-IoT/GSM
|
| GNSS |
GNSS: L1: GPS, GLONASS, GALILEO, BEIDOU, SBAS*, QZSS*, DGPS*, AGPS*
* Optional models available with custom firmware applications, for more
information contacts your sales manager.
Receiver: 33 tracking channel
99 acquisition channel
Tracking sensitivity: -165 dBM
Position Accuracy: < 2.5 m CEP
|
| Cellular |
Technology: GSM/GPRS
2G bands: GSM: B2/B3/B5/B8
4G LTE bands: LTE-FDD (CAT M1):
B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B27/B28
LTE-FDD (CAT NB2): B1/B2/B3/B4/B5/B8/B12/B13/B18/B19/B20/B28
Data transfer: LTE: Max. 588Kbps (DL)/Max.1119Kbps (UL)
GPRS: Max. 107Kbps (DL)/Max. 85.6Kbps (UL)
Transmit power: Class 4 for GSM850/900: 23±2dBm
Class 1 for GSM1800/1900: 20±2dB m
Class 3 for LTE-TDD: 23±2.7dBm
Class 3 for LTE-FDD: 23±2.7dBm
Bluetooth® LE: -6.6 dBm
Data support: SMS (TEXT), Network protocols (TCP,UDP)
|
| Battery and power |
Internal battery: Extremely low self-discharge Li-SOCl2 swappable,
non-rechargeable battery, 7,2V 2200mAh
Battery life: Up to 5 years (when used as a backup tracker only via Bluetooth®)*
Up to 4 years (1 LBS – cell towers report per day)*
Up to 3 years (1 GNSS report per day)*
*Battery life estimates are influenced by many factors such as outdoor temperature, frequency of reporting, installation, and orientation of the device, network coverage, additional functionalities (like Bluetooth® scanning enabled) and more.
|
| Bluetooth® |
Specification: 5.2 + LE
Supported peripherals: EYE Sensors, EYE Beacons (recovery mode only),
Universal Bluetooth® LE sensors support
|
| Physical specification |
Dimensions: 78 x 63 x 28 mm (L x W x H)
Weight: 115 g (when 2 cell batteries are used)
|
| Operating environment |
Operating temperature (with battery): -35 °C to +75 °C
Storage temperature (with battery): -40 °C to +85 °C (Recommended max. 30°C)
Operating temperature (without battery): -20 °C to +60 °C
Operating humidity: 5% to 95% non-condensing
Ingress Protection Rating: IP68
Battery discharge temperature: -60 °C to +85 °C
Battery storage temperature: Recommended max. 30°C
|
| Interface |
GNSS antenna: Internal High Gain
Cellular antenna: Internal GSM High Gain
USB: 2.0 Micro-USB
LED indication: 1 status LED light
SIM: Micro-SIM
Memory: 128MB internal flash memory
|
| Features |
Scenarios: Accelerometer wake up, GNSS, Bluetooth® sensor support, Recovery mode, Periodic tracking on stop / on move, Scheduler with time zones, Backup tracking, Static navigation, Lost BLE sensor
Sensors: Accelerometer
Sleep modes: Single custom sleep mode
Configuration and firmware update: FOTA WEB, Teltonika Configurator (USB)
SMS: Configuration, Events, Debug
GPRS commands: Configuration, Debug
Time Synchronization: GNSS, NITZ, NTP
|
| Certification & approvals |
Regulatory: AT&T, FCC, IC, PTCRB, Anatel
|
