ASTRA AT240

Description

• Product Specifications:

  • Processor: Cortex M3 ARM processor for efficient performance.​Plaspy

  • GNSS Module: SiRFstar IV GPS chip supporting multiple satellite navigation systems with high sensitivity and anti-jamming features.​ManualsLib+1Plaspy+1

  • Communication Module: Telit GE865 Quad Band GSM/GPRS modem supporting 850/900/1800/1900 MHz frequencies.​ManualsLib+1ManualsLib+1

  • Power Supply: Operates from a DC voltage between 5 and 50 volts.​ManualsLib+1ManualsLib+1

  • Backup Battery: Internal 450mAh lithium-polymer battery, providing approximately 3 hours of continuous operation or up to 3 days in hourly update mode.​ManualsLib

  • Inputs/Outputs:

    • 6 digital inputs.

    • 5 digital outputs.

    • 2 RS232 serial ports.

    • 2 analog-to-digital converter (ADC) inputs.

    • CANBus interface.

    • 1-Wire interface for driver identification (iButton) or temperature sensing.

  • Antennas: Internal GPS and GSM antennas; option for external GPS antenna via SSMB connector.​

  • Ingress Protection: IP67-rated, ensuring protection against dust and water immersion.​

  • Dimensions: 104 x 85 x 24 mm.​ManualsLib

  • Weight: Approximately 80g.​

• Features:

  • Real-time Tracking: Provides accurate, real-time location updates for vehicles.​

  • Geofencing: Allows setting up virtual boundaries with alerts when the vehicle crosses them.​

  • Driver Identification: Supports iButton for driver ID applications, enhancing security and accountability.​

  • CANBus Integration: Compatible with FMS and OBD protocols for vehicle diagnostics and monitoring.​

  • Low Power Consumption: Operates efficiently with minimal power usage, featuring sleep modes to reduce battery drain when the vehicle is stationary.​

  • Over-the-Air (OTA) Updates: Supports firmware updates remotely, ensuring the device remains up-to-date with the latest features and improvements.​

  • Durable Design: Compact form factor with a robust, waterproof enclosure, suitable for various installation environments.
